Operation Section

5.2 Control Box

(1) For unit serial number from 0415XXXXC12 to Present

*:Please refer to page 2 for the position of the name plate showing the serial number on the unit.

ILL00956-00

CF1: Capacitor for

Evaporator Fan Motor

CF2: Capacitor for

Condenser Fan Motor

TB2: Terminal Block2

RB: Relay Board

TB1: Terminal Block1

CC: Capacitor for Compressor

4-Position Dipswitch

"OFF" Position

RX: Auxiliary Relay
