Operation Section

4. REFRIGERATION SYSTEM

4.1 Refrigeration System Construction

The component parts of the refrigeration system include the following:

• Compressor, Evaporator, Condenser, Accumulator, Capillary tube, High pressure switch

These parts are all connected by copper tubing. All the connections have been brazed.

ILL00534-00

Accumulator

Compressor

Connecting Tube

High Pressure Switch

Evaporator

Accumulator

Compressor

Connecting Pipe

Evaporator Inlet Pipe

Condenser

Evaporator

Condenser

Outlet Pipe

Condenser

Inlet Pipe

Compressor

Suction Pipe

(Insulated)

Evaporator Outlet PipeAssy

Compressor

Discharge Pipe

Capillary Tube

Fan

Motor

Capillary

Tube

Refrigerant

Flow
